Leading time before shipping: 3-5 weeks

For creating lightweight configurations, short length, easy pedaling

This frame design is based on users' needs to easily control the bicycle and pedal comfortably. Engineers made it as light as possible while taking into account potential overloads on the structure. The strength is sufficient for riding on rough terrain and even small jumps. The frame features a solution with removable dropouts, thickness 11mm. Material: Stainless steel ANSI 304 (American). Brake caliper standard: 160mm IS. Threaded hole for installing a gear shifter.

Package includes:

Battery compartment
Swingarm
Bike bracket
Shock absorber bracket
Battery compartment covers, 4 pcs
Swingarm bearings, swingarm axle spacer, shock absorber and swingarm axles, inter-block screws, washers, and nuts, stainless steel dropouts

Compatible bicycle parts:

Rear brake mount: IS 160-203mm rotors
Bottom bracket: 68mm, spindle length 122mm and longer
Headset: Semi-integrated, cups for 44mm
Seatpost: 30.6 - 30.8 mm
Suspension fork: travel 80-200mm
Rear shock: mounting width 24mm, axle 8mm. 160mm for fork travel of 80-90mm, 180mm for fork travel of 100-140mm, 190mm for fork travel of 140-160mm, 200mm for fork travel of 200mm
Wheels and tires (bicycle): 24" - 64mm rim, tire up to 2.5", 26" - 45mm rim, tire up to 2.5"
Wheels and tires (motorcycle): 19” rim with 2.7” tire, 18” rim with 3.6” tire, 17” rim with 4.2” tire

Technical specifications:

Wheelbase: 1150mm when using a fork with 200mm travel
Compartment width: 100mm
Maximum dimensions of removable battery: 310x160x80mm
Allowable number of 18650 cells for removable battery: 160+ pcs
Maximum dimensions of static battery: 350x180x95mm
Allowable number of 18650 cells for static battery: 220+ pcs
Swingarm leverage ratio: 1/3.7 or 1/4.5
Variable-width swingarm: yes
Reinforcements inside swingarm: yes
Width between dropouts: 145mm
Maximum wheel width: 64mm
Bottom bracket position: under the battery compartment
Head tube: 130mm
Bottom bracket: 68mm
Seat options: bicycle / motorcycle
Maximum wheel diameter: 700mm
Dropouts: removable, vertical with a slight angle
Hole for chain tensioner: yes
Rake (fork angle): 20-30 degrees
Battery loading: from the side / top
Rear shock: bicycle
Rear shock length: 190-220mm
Maximum chainring teeth: 52
Geometry: mountain bike
Weight: 8.5 kg
Load capacity: 120 kg
